Wiska Combi 1010 Junction Box - COMBI 1010 BLACK 10062215

Wiska COMBI 1010

Wiska COMBI 1010/5 - Black

£21.49
In Stock
EACH
£21.49
3+
£20.41
5+
£19.39
payment methods

The Wiska COMBI 1010 is the next size up from the Combi 607 and being bigger allows for connections for 10mm Cable or 57 amps. This weather rated IP66 / IP67 Junction box has total of 10 knockout entries to the side of the box with a rubber membraine. A very quick and easy solution for connecting cables in all conditions making this product perfect for LED Lighting / Flood lights and CCTV systems.

Dimensions: 140mm x 140mm x 82mm (Empty Box Volume approx 1ltr)

Complete with a 5 way Terminal Block 57amp / 10mm rated

Knockouts: 5 x 25mm/32mm, 2 x 20mm, 3 x 20mm/25mm cable entries to use with Wiska Combression Glands or SWA Glands

4 x Knockout Cable entries in the base - 2 x 25mm/32mm + 2 x 20mm/25mm

Protection class: IP66/IP67

Operating temperature: -30°C to 100°C

Installation temperature: -5°C to 60°C

Available in BLack, Grey and White

  • PRODUCT DESCRIPTION
    General
    ColourBlack
    Depth82mm
    Length140mm
    Width140mm
    IP RatingIP66
    MountingSurface
    Dimensions140mm x 140mm x 82mm
    Cable Management
    Product RangeCOMBI series
    Maximum Operating Temperature100°C
    Minimum Operating Temperature-30°C
    Material Polypropylene
    Number of Knockouts10
    TypeWiska COMBI 1010
